NOAA 19 APT images




In 2014 I replaced the QFH antenna from Winkler with another QFH antenna from Vierling. The results are better, however the environment changed too as I had to take down my dish antenna for maintenance. So the final judgement will only be possibly once the dish is reinstalled.
The receiver is controlled with the software from Vierling called "Weatherman Control" and the
audio is processed in the soundcard of the PC using the registered version of the software WXtoImg.
You can find a quite detailed description of the Weatherman Set and how to optimize the antenna
in the"Ham Downloads" section of this website or when clicking on the picture on the right.
